Input Features | ||
Audio | 1 x S/PDIF Out header | |
Fans | 1 x CPU fan header 1 x system fan header | |
Misc | 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only) 1 x speaker header 1 x Clear CMOS jumper 1 x chassis intrusion header | |
Power | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector | |
Storage | 4 x SATA 6Gb/s connectors | |
USB | 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers | |
Output Features | ||
Audio | 3 x audio jacks (Line In, Line Out, Mic In) | |
Misc | 1 x PS/2 mouse port | |
Network | 1 x RJ-45 port | |
USB | 4 x USB 3.1 Gen 1 ports | |
Video | 1 x D-Sub port | |
Physical Specification | ||
CPU | Supports AMD 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 1st Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ 1st Gen Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ 7th Gen A-series/ Athlon X4 Processors | |
Audio | Realtek® audio codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYT | |
LAN | Realtek® GbE LAN chip (10/100/1000 Mbit) | |
Expansion Slots | 1 x PCI Express x16 slot, running at x16 (PCIEX16) * Actual support may vary by CPU. (The PCIEX16 slot conforms to PCI Express 3.0 standard.) 2 x PCI Express x1 slots (The PCI Express x1 slots conform to PCI Express 2.0 standard.) | |
USB | 2 x USB 3.1 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) CPU: 4 x USB 3.1 Gen 1 ports on the back panel | |
Technical Specification | ||
Operating System | Support for Windows 10 64-bit Support for Windows 7 64-bit * To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge, Summit Ridge and Bristol Ridge CPU. * Please download the "Windows USB Installation Tool" from GIGABYTE's website | |
General | ||
Manufacturer | Gigabyte | |
Year | January 25, 2018 | |
Socket(s) | AM4 | |
Form Factor | Micro ATX Form Factor; 24.4cm x 19.5cm | |
Chipset | AMD A320 | |
Memory Specifications | ||
Slot Protocol | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2(Note) SSD support) * Actual support may vary by CPU. | |
Slot Type | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
Maximum Speed | Support for DDR4 3200(O.C.)/2933(O.C.)/2667*/2400/2133 MHz memory modules * Actual support may vary by CPU. | |
Maximum Capacity | 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory | |
Maximum Channels | Dual channel memory architecture | |
ECC support | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
Graphics Specifications | ||
Integrated Graphics Processor | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution | |
Warranty Information | ||
Warranty | 3 Years | |
Warranty | 3 Years |
