Input Features | ||
Audio | 1 x front panel audio header 1 x speaker header | |
Fans | 1 x CPU fan header 2 x system fan headers | |
Misc | 1 x RGB LED strip header 1 x M.2 Socket 3 connector | |
Power | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector | |
Storage | 4 x SATA 6Gb/s connectors | |
USB | 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header | |
Output Features | ||
Audio | 3 x audio jacks | |
Misc | 1 x PS/2 keyboard/mouse port | |
Network | 1 x RJ-45 port | |
USB | 4 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports | |
Video | 1 x DVI-D port 1 x HDMI port | |
Physical Specification | ||
CPU | AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™ and 3rd Gen Ryzen™ with Radeon™ Graphics Processors | |
Audio | Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABY | |
LAN | Realtek® GbE LAN chip (1000 Mbit/100 Mbit) | |
Expansion Slots | x PCI Express x16 slot, integrated in the CPU: 3rd Generation AMD Ryzen™ processors support PCIe 4.0 x16 mode 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors support PCIe 3.0 x16 mode 2 x PCI Express x1 slots (PCIEX1_1, PCIEX1_2), in | |
USB | 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB headers 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB headers) | |
Technical Specification | ||
Operating System | Support for Windows 10 64-bit | |
General | ||
Manufacturer | Gigabyte | |
Socket(s) | AM4 | |
Form Factor | Micro ATX Form Factor; 24.4cm x 20.5cm | |
Chipset | AMD B550 | |
Memory Specifications | ||
Slot Type | Support for Extreme Memory Profile (XMP) memory modules | |
Maximum Speed | AMD Ryzen™ 5000 series processors: Support for DDR4 4266(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules 3rd Gen AMD Ryzen™ Pro | |
Maximum Capacity | 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory | |
Maximum Channels | Dual channel memory architecture | |
ECC support | Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
Graphics Specifications | ||
Integrated Graphics Processor | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution | |
Warranty Information | ||
Warranty | 3 Year's (Official) |
