Physical Specification | ||
LED | RGB | |
Fan Power Connector | 4-Pin (PWM) | |
Technical Specification | ||
CPU Socket | LGA2066, LGA2011-v3, LGA2011, LGA1366, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150, LGA775, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1 | |
Fan Speed | 600-1800 RPM ± 10% | |
Fan Airflow | 53.4 CFM ± 10% | |
Fan Air Pressure | 1.65 mmH2O ± 10% | |
Fan Noise Level | 31 dBA (Max) | |
Fan Rated Voltage | 12VDC | |
Fan Rated Current | 0.30A | |
Fan Safety Current | 0.37A | |
Fan Power Consumption | 3.6W | |
General | ||
Model | MA620P | |
Product Number | MAP-D6PN-218PC-R1 | |
Series | MasterAir | |
Type | Air Cooler | |
Physical Description | ||
Heat Sink Dimensions | 116 x 110.1 x 165 mm / 4.6 x 4.3 x 6.5 inch | |
Heat Sink Weight | 850g / 1.87lb | |
Heat Pipe Dimensions | Ø6mm | |
Fan Dimensions | 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch | |
Fan MTTF | 160,000 Hours | |
Additional Info | ||
Heat Sink Material | 6 Heat Pipes, CDC 2.0, Aluminum Fins | |
Warranty Information | ||
Manufacturing Warranty | 02 Years |
A wired RGB LED controller is included 100M to personalize the RGB lighting anytime you want (no software needed). Switch it up depending on your mood, the possibilities are not limitless.
Tool-free mounting kit makes installation a breeze. Universal retention brackets are included, with full compatbiliity for:
Intel© LGA 1151 / 1150 / 1155 / 1156 / 1366 / 775
AMD© AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1
