Main Feature | ||
Model | TS256GMTS832S | |
Capacity | 256GB | |
Interface | SATA III 6Gb/s | |
Form Factor | 2280-S2-B-M (Single-sided) | |
Flash Type | NAND Flash 3D TLC | |
MTBF | 2,000,000 hour(s) | |
Physical Specification | ||
Dimensions | 80.0 mm x 22.0 mm x 2.23 mm (3.15" x 0.87" x 0.09") | |
Weight | 9g | |
Additional Info | ||
Operating Temperature | 0°C ~ 70°C | |
Operating Voltage | 3.3V±5% | |
R/W Speed | 530/400 MB/s | |
Warranty Information | ||
Manufacturing Warranty | 05 Years |
Unlike the existing planar NAND chips, 3D NAND flash is a type of flash memory in which the memory cells are stacked vertically in multiple layers. 3D NAND is developed to break through density limitations of the 2D planar NAND, and thus can deliver a greater level of performance and endurance.
Compliant with M.2 form factor Type 2280, Transcend's 3D NAND M.2 SSD 832S is just 80mm in length and comes in a single-sided layout - meaning that only one side of the SSD has components attached to it - making the 832S the perfect solution for small form factor laptops and ultra-light PCs. The M.2 SSD 832S makes for an easy upgrade to your computer, taking up little space while giving it a much needed energy boost.
Featuring the M.2 standard (80mm), the next generation SATA III 6Gb/s interface and a powerful controller, Transcend's M.2 SSD 832S reaches incredible read and write speeds of up to 560MB/s and 500MB/s. When used as a cache, the M.2 SSD 832S provides 1.5 times faster boot time than conventional hard drives.
Dedicated to maximizing high-performance computing, the M.2 SSD 832S features 4k random file read and write speeds up to 85,000 IOPS that deliver incredibly short loading times and almost instant response for heavy graphics and multimedia applications.
The M.2 form factor enables expansion and integration of functions onto a single form factor module solution. M.2 SSDs include a smaller form factor but with larger capacities than that of mSATA and half-slim SSDs. With its singled-sided M.2 form factor, the SSD 832S is even slimmer and offers better compatibility.
Despite its extra-small dimensions, the M.2 SSD 832S boasts a DDR3 DRAM cache and contains advanced features to enhance the performance of the SSD.
Detects and corrects transfer errors to prevent data corruption
Relocates existing data to release memory blocks
Distributes data evenly across memory cells to prolong SSD's lifespan
Stores a temporary copy of the most active data to shorten access times
