Physical Specification | ||
Interface | SATA III 6Gb/s | |
Shock Resistance | 1500G/0.5ms | |
Technical Specification | ||
Flash Type | V-NAND 3bit MLC | |
Read Speed (Max.) | 550MB/s | |
Write Speed (Max.) | 520MB/s | |
Random Read IOPS | Up to 10,000 | |
Random Write IOPS | Up to 42,000 | |
AES Encryption | 256-bit | |
TRIM Support | Yes | |
S.M.A.R.T Support | Yes | |
ECC Support | Yes | |
MTBF | 1,500,000 hours | |
General | ||
Model | Samsung 860 EVO | |
Type | SATAIII SSD | |
Form Factor | 2.5 Inch | |
Capacity | 500GB | |
Physical Description | ||
Dimensions | 100 x 69.85 x 6.8mm | |
Weight | 50 gm | |
Warranty Information | ||
Manufacturing Warranty | 03 Years |
The newest edition to the world’s best-selling* SATA SSD series, the Samsung 860 EVO. Specially designed for mainstream PCs and laptops, with the latest V-NAND and a robust algorithm-based controller, this fast and reliable SSD comes in a wide range of compatible form factors and capacities.
* Sources: NPD (US data from Jan. 2015 to Oct. 2017) and GfK (EU5 data from Jan. 2015 to Sep. 2017, China data from Jan. 2016 to Sep. 2017)
Speeds are more consistent, even with heavy workloads and multi-tasks. The 860 EVO performs at sequential writes up to 520 MB/s* with Intelligent TurboWrite technology, and sequential reads up to 550 MB/s. The TurboWrite buffer size* is upgraded from 12 GB to 78 GB for faster file transfer.
* Performance may vary based on SSD’s firmware version and system hardware & configuration. Sequential write performance measurements are based on Intelligent TurboWrite technology. Sequential performance measurements based on CrystalDiskMark v.5.0.2 and IOmeter 1.1.0. The sequential write performances after Intelligent TurboWrite region are 300 MB/s for 250/500 GB and 500 MB/s for 1 TB. * Test system configuration: Intel Core i5-3550 CPU @ 3.3 GHz, DDR3 1333 MHz 4 GB, OS – Windows 7 Ultimate x64, Chipset: ASUS P8H77-V * The TurboWrite buffer size varies based on the capacity of the SSD‡ 12 GB for 250 GB model, 22 GB for 500 GB model, 42 GB for 1 TB model and 78 GB for 2/4 TB. For more information on the TurboWrite, please visit www.samsungssd.com.
Benefit from faster, more fluid communication with your host system. The refined ECC* algorithm and a new MJX controller generate higher speeds, and the improved queued trim enhances Linux compatibility. Our advanced engineering makes the 860 EVO more compatible with your computing system.
* Error Correction Code
Whatever size your computer needs, there is an 860 EVO for you. Choose among the 2.5-inch size for desktop PCs and laptops, and the SATA-based M.2 (2280) or the mSATA for ultra-slim computing devices.
Samsung Magician software is designed to help you manage your SSD with a simple and intuitive user interface.
Get notifications when new firmware is released, and easily install updates for enhanced performance, stability, and compatibility.
Check your SSD's sequential and random read/write speeds, so you can maintain superb performance.
Protect data by selecting security options. The 860 EVO supports AES 256-bit hardware-based encryption and is compliant with TCG Opal and IEEE 1667.
Model - Samsung 860 EVO, Type - SATAIII SSD, Storage (GB/TB) - 500GB SSD, Form Factor - 2.5 Inch, Interface - SATA III 6Gb/s, Flash Type - V-NAND 3bit MLC, Read Speed (Max.) - 550MB/s, Write Speed (Max.) - 520MB/s, Random Read IOPS - Up to 10,000, Random Write IOPS - Up to 42,000, Shock Resistance - 1500G/0.5ms, AES Encryption - 256-bit, TRIM Support - Yes, S.M.A.R.T Support - Yes, ECC Support - Yes, MTBF - 1,500,000 hours, Dimension - 100 x 69.85 x 6.8mm, Weight - 50 gm, Others - Buffer (MB): 512MB LPDDR4, STORAGE MEMORY: Samsung V-NAND 3bit MLC, CONTROLLER: Samsung MJX Controller, TRIM SUPPORT, S.M.A.R.T SUPPORT, GC (GARBAGE COLLECTION): Auto Garbage Collection Algorithm, WWN SUPPORT, DEVICE SLEEP MODE SUPPORT, RANDOM READ (4KB, QD32): Up to 98,000 IOPS, RANDOM WRITE (4KB, QD32): Up to 90,000 IOPS, RANDOM READ (4KB, QD1): Up to 10,000 IOPS, RANDOM WRITE (4KB, QD1): Up to 42,000 IOPS, RELIABILITY (MTBF): 1.5 Million Hours Reliability, SHOCK: 1,500 G & 0.5 ms (Half sine), Specialty: TRIM (Required OS support), Garbage Collection, S.M.A.R.T, AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive(IEEE1667), Enhanced Computing Experiences, Worry-Free Reliability, Expanded Compatibility with a Refined Controller, Advanced Data Encryption, Samsung Data Migration and Magician Software, Part No - MZ-76E500BW, Warranty - 3 year, Country of Origin - Korea
