Physical Specification | ||
Fan Size | 120mm | |
Fan Bearing | Sleeve Fan | |
Protections | OVP, OPP, OTP, SCP | |
MB 24-Pin Connectors | 1 | |
CPU 12V 4+4 Pin Connectors | 1 | |
SATA Connectors | 6 | |
Peripheral 4-Pin Connectors | 3 | |
FDD Cable 4-Pin Connectors | 1 | |
PCI-e 6+2 Pin Connectors | 1 | |
Technical Specification | ||
Input Frequency | 50-60Hz | |
Power Good Signal | 100 - 500 ms | |
Hold Up Time | >10ms at 100% Full Load | |
Efficiency | 75% @ Typical Load | |
MTBF | >100,000 Hours | |
Operating Temperature | 10-40°C | |
Regulatory | TUV, cTUVus, CE, FCC, BSMI | |
General | ||
Model | MPW-4001-ACAAN1 | |
Product Name | Elite V3 400W | |
ATX Version | ATX 12V V2.31 | |
PFC | Active PFC (>0.9 typical) | |
Power | ||
Input Voltage | 100-240V | |
Input Current | 8-4A | |
Physical Description | ||
Dimensions | 150 x 140 x 86 mm | |
Warranty Information | ||
Manufacturing Warranty | 02 Years |
