Main Feature | ||
Storage | 512GB | |
Interface(s) | PCIe Gen3 x4 | |
Flash Type | 3D TLC NAND flash | |
Shock Resistance | 1500G/0.5msec | |
MTBF | 1,500,000 hours | |
Physical Specification | ||
Form Factor (Inch) | M.2 2280 | |
Dimensions | 80 x 22 x 2.38 mm | |
Weight | 6.80 gm | |
General | ||
Brand | Apacer | |
Model | Apacer AS2280P4 | |
Type | Internal SSD | |
Part No | AP512GAS2280P4-1 | |
Power | ||
Power Consumption | 4000 mW (Active mode), 70mW (Power State) | |
Warranty Information | ||
Warranty | 3 year | |
Performance | ||
Read Speed (Max.) | 3000MB/s | |
Write Speed (Max.) | 2000MB/s |
Brand - Apacer, Model - Apacer AS2280P4, Storage (GB/TB) - 512GB, Type - Internal SSD, Form Factor - M.2 2280, Interface - PCIe Gen3 x4, Flash Type - 3D TLC NAND flash, Read Speed (Max.) - 3000 MB/s, Write Speed (Max.) - 2000 MB/s, Shock Resistance - 1500G/0.5msec, TRIM Support - Yes, S.M.A.R.T Support - Yes, MTBF - 1,500,000 hours, Power Consumption - 4000 mW (Active mode), 70mW (Power State), Dimension - 80 x 22 x 2.38 mm, Weight - 6.80 gm, Others - Vibration: 7 - 800Hz, 3.08Grms, Operating Temperature: 0 degree C - 70 degree C, Storage: -40 degree C - 85 degree C, Supply Voltage: 3.3 V +- 5%, Connector Type: 75-pin M.2 module pinout, Frequency: 20Hz - 80Hz, Certificate: KCC, CE, FCC, VCCI, RCM, BSMI, Specialty - The AS2280P4 SSD has built-in protection technology to ensure data integrity and stability, It is definitely the top choice for ultra-thin Laptops, e-sports consoles, and mini-PCs., Part No - AP512GAS2280P4-1, Warranty - 3 Year, Country of Origin - Taiwan, Made in/ Assemble - Taiwan
