Antec HCG 850 EC Gold High Current Gamer Gold Series 850W Power supply
Price : TK.0
Brand : Antec
Model : Antec HCG 850 EC Gold
Warrantty : 10 Year's (Official)
Product Code : TLB-424
Status :
- Out of stock
Payment:
Share:
Related Products
Specificaions :
| Input Features | ||
| Input Voltage | 100-240 VAC ±10% | |
| Input Current | 12A-6A | |
| Input Frequency Range | 50Hz-60Hz | |
| Physical Specification | ||
| Fan | 120mm FDB Fan | |
| Number of Pin | 1 x MB 24(20+4) | |
| Pin EPS 12V | 2 x 8(4+4) | |
| Pin PCI-E | 6 x 8(6+2) | |
| SATA | 10 | |
| Molex | 5 | |
| FDD | 1 | |
| Technical Specification | ||
| PFC | Active PFC (>0.9 typical) | |
| Power Good Signal | 100-500ms | |
| Efficiency | 92% Typically | |
| Protection | OCP/OVP/UVP/SCP/OPP/OTP/SIP/NLO | |
| Output Capacity | 850W | |
| Operation Temperature | 0~40°C | |
| General | ||
| Model | Antec HCG850 Gold | |
| Type | ATX 12V 2.4 | |
| Modular | Fully Modular | |
| Certifications | 80 Plus Gold | |
| Physical Description | ||
| Dimensions | 140 x 150 x 86 mm | |
| Weight | 3.77Kg | |
| Additional Info | ||
| Regulatory | cTUVus/TUV/CB [IEC62368 Compliant] /RCM/CE/EAC/CCC/BSMI/FCC/KR | |
| Warranty Information | ||
| Manufacturing Warranty | 10 Years | |
FEATURES
- Guaranteed 850W of Continuous Power from Antec
- 100% Modular－Improves airflow and reduces clutter
- 80 PLUS® GOLD certified－Up to 92% efficient, to reduce your electricity bill
- PhaseWave™ Design－A server-class full-bridge LLC design with a synchronous rectification based on a DC-DC topology
- Antec Quality 10-year warranty and lifetime global 24/7 support
- 120mm FDB Silence－Whisper-quiet high-quality fluid-dynamic bearing fan with long lifetime
- Zero RPM Manager－An advanced low voltage fan control with fan-off mode at low loads for absolute silence
- 99%+12V - Output for maximum CPU & GPU support
- CircuitShield™－Full suite of industrial grade protections: OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO
- 100% Japanese capacitors achieve unprecedented tight voltage regulation & low ripple & noise to maximize your system’s performance
- 28(18+10) pin MBU socket - For possible future MBU connectors
- ATX12V 2.4－Engineered according to the newest PSU guideline and compatible with the latest CPU generation
- Compact size 140mm depth power supply is the best choice for compact ATX chassis
